셀 컬쳐 플레이트용 인서트, BRAND Insert 2in1 BRAND Insert 2in1 for Cell Curture Plate
■ 2D & 3D Cell Culture 용
■ Hanging 또는 Standing Position 기능을 선택 사용 가능 ( 2 in 1 )
■ 6-, 12- & 24-well Plate 또는 Culture Dish 와 같이 사용
■ Uniform and Controlled Cell Growth
■ CellGrade™ plus surface of Membrane : Optimal Cell Attachment & Growth
■ Sterile according to ISO 11137, Sterility Assurance Level SAL 10-6
■ Non-cytotoxic according to ISO 10993-5
■ Free of Pyrogen & Endotoxins, according to LAL test(< 0.01 EU/ml)
BRAND Insert 2in1 Track-etched Membrane 종류 및 특성
| Type | PET membrane | PC membrane |
|---|
| Pore Size | 0.4 um | 0.8 um | + | + |
| Pore Density | 1 x 108 cm2 | 1 x 105 cm2 | 2 x 106 cm2 | 1 x 105 cm2 |
| Optic | 반투명(Translucent) | 반투명(Translucent) | 투명(Transparent) | 반투명(Translucent) |
| Property | Extremely thin and stable membrane with defined pore sizes and pore density, which can easily be further processed after separation from the insert housing. Compatible with the most common fixation and staining protocol | Ultra-thin membrane with low autofluorescence, also usable without additional layer, provides optimal support for proliferation and differentiation. Compatible with the most common fixation and staining protocols |
with PC Membrane
| Cat. No | Model | Well | Pore Size | Diameter | Blister 포장 |
|---|
| P04-59-701 | 782700 | 24-well | 0.4 um | Ø8.8 mm | Single (개별) |
| P04-59-703 | 782701 | Multi-pack (4 x 12) |
| P04-59-705 | 782706 | 8.0 um | Single (개별) |
| P04-59-707 | 782707 | Multi-pack (4 x 12) |
| P04-59-709 | 782720 | 12-well | 0.4 um | Ø13.3 mm | Single (개별) |
| P04-59-711 | 782721 | Multi-pack (4 x 9) |
| P04-59-713 | 782726 | 8.0 um | Single (개별) |
| P04-59-715 | 782727 | Multi-pack (4 x 9) |
| P04-59-717 | 782740 | 6-well | 0.4 um | Ø24.8 mm | Single (개별) |
| P04-59-719 | 782741 | Multi-pack (4 x 6) |
| P04-59-721 | 782746 | 8.0 um | Single (개별) |
| P04-59-723 | 782747 | Multi-pack (4 x 6) |
* Highly Transparent Membrane (PET) : Detailed Observation of Cell Culture under an Optical Microscope
with PET Membrane
| Cat. No | Model | Well | Pore Size | Diameter | Blister 포장 |
|---|
| P04-59-731 | 782710 | 24-well | 0.4 um | Ø8.8 mm | Single (개별) |
| P04-59-733 | 782711 | Multi-pack (4 x 12) |
| P04-59-735 | 782716 | 8.0 um | Single (개별) |
| P04-59-737 | 782717 | Multi-pack (4 x 12) |
| P04-59-739 | 782730 | 12-well | 0.4 um | Ø13.3 mm | Single (개별) |
| P04-59-741 | 782731 | Multi-pack (4 x 9) |
| P04-59-743 | 782736 | 8.0 um | Single (개별) |
| P04-59-745 | 782737 | Multi-pack (4 x 9) |
| P04-59-747 | 782750 | 6-well | 0.4 um | Ø24.8 mm | Single (개별) |
| P04-59-749 | 782751 | Multi-pack (4 x 6) |
| P04-59-751 | 782756 | 8.0 um | Single (개별) |
| P04-59-753 | 782757 | Multi-pack (4 x 6) |
* With High Pore Density Membrane (PC) : High Permeability
* 그 외 규격은 가격문의 부탁드립니다.
